Multi-Point VI SPA Conductive Silicone Gasketing

CSI Multi-Point VI SPA gasketing material uses plated aluminum particles in a specially formulated silicone elastomer. This material exhibits exceptional environmental, electrical and physical characteristics. It is similar in performance to our top of the line MP VI SPC but contains less silver.


  Volume Resistivity in ohm-cm .008 Max
  Tensile Strength in PSI 200
  Elongation (at rupture) 270%
  Temperature Range -55° to +200° C
  Hardness, Shore A 60 ± 5
  Specific Gravity 1.83 ±.05
  Tear Strength, (Ibs/in) 38
  Deflection at 100 PSI in Percent 7
  Color tan

Shielding Effectiveness:**

  14 Khz (Magnetic field)  71 db
  1.0 Mhz (Electric field) 120 db
  1.0 Ghz (Plane Wave) 110 db

* Above specifications are based on a 60 duro material; other compounds will exhibit similar properties.
** Test Method: MIL-STD-285
